2 General Information
This manual describes the drive amplifiers of the series SD2B / SD2B plus. These
devices allow operation of high-dynamic servo motors as well as synchronous and
asynchronous high-frequency spindles.
The devices are equipped with interfaces for different sensor systems and allow the
operation of motors with Hall and incremental sensors. Motor systems without any
sensors are also supported, whereas different customized control methods are avail‐
able. In addition, the devices can drive rotary and linear motors. Thus, the number of
device variants is reduced for the machine manufacturer.
This manual provides information on:
▶ Safety instructions and application advice
▶ Notes about the electromagnetic compatibility
▶ Description of the device (block diagram, type plate, module designation)
▶ Technical data, dimensions
▶ Connector pin assignment
▶ Wiring examples
▶ Status and error messages
▶ General information regarding the wiring (cables and line cross-sections)
This manual has the following demands on the trained staff of machine manufacturers:
Transport: only by skilled employees familiar with handling electrostatically
sensitive components.
Installation: only by experts with electromechanical experience
Initial operation: only by experts with experience in the fields of electrical engi‐
neering / drive technology
Information concerning the initial operation and parameterization of the
digital drive amplifier can be found in the manual of the software
drive‐
master2
.
More documentation can be downloaded from the SIEB & MEYER website
under http://www.sieb-meyer.de/downloads.html.
W
General Information
Drive Amplifier SD2B / SD2B plus - Hardware Description 11
