6 Device variant SD2B
Fig. 2: Device view of SD2B (0362170DB)
6.1 Operating Instructions
With its single-board design the device is to be integrated into the customer's electrical
construction on a sufficient cooling surface.
DANGER
Operating voltages above 48 V
In order to avoid personal injuries provide for protection against contact when oper‐
ating voltages above 48 V are reached (e.g. install the device in a switch cabinet).
WARNING
Hot surfaces
During operation the heat sink and components can reach temperatures above
80 °C.
Do not touch the device during operation.
Make sure that there are no combustible materials near by the device and that the
heat sink is not covered during mounting and operation.
Take measures to protect the device against contamination, in particular due to
conductive or aggressive materials. Contamination can cause malfunctions and short-
circuits.
