Code Error message Error reaction Possible reason
E47
(0x52F)
(1327
d
)
Drive parameters not activated
Power output stage can not be
activated.
▶ Drive start is not acknowledged by
master yet (configurable by
parameters in software).
E55
(0x737)
(1847
d
)
Firmware stopped by ESC
Device stops in BIOS. ▶ During boot-up the device received
an ESC sequence at the serial
interface.
E56
(0x738)
(1848
d
)
Device configuration
Device stops in BIOS. ▶ During boot-up the device detected
that hardware, firmware parame‐
ters and logic are not consistent; a
detailed error description is
received by a parameter download.
E57
(0x739)
(1849
d
)
Faulty or no firmware
Device stops in BIOS. ▶ During boot-up the device detected
no firmware or a faulty firmware.
E58
(0x73A)
(1850
d
)
FPGA watchdog triggered
Device stops in BIOS. ▶ FPGA process monitoring has
been triggered; please contact
SIEB & MEYER.
E59
(0x73B)
(1851
d
)
No drive parameters loaded
Device stops in BIOS. ▶ Device is not parameterized (status
of delivery).
E60
(0x73C)
(1852
d
)
Drive parameters incorrect
Device stops in BIOS. ▶ Parameter set of the device is not
valid (CRC error).
E61
(0x73D)
(1853
d
)
Logic coding missing or incorrect
Device stops in BIOS. ▶ Logic programming of the device is
not valid.
E62
(0x73E)
(1854
d
)
Error in electronic type plate
Device stops in BIOS. ▶ Type plate is not programmed or
faulty; please contact
SIEB & MEYER.
(1)
For servo motors with commutation via an incremental motor measuring system the warning W17
“Unknown commutation angle ” is signaled. After a restart of the device the phasing of the motor measuring
system starts automatically (magnetic alignment).
10.3 List of Warning Messages
Warning messages are not displayed on the device display. They can only be seen in
the software
drivemaster2
via “Diagnosis ÿ Errors and warnings”.
Code
Description
W00 Digital input 'Quick stop' active
W01 Digital input 'Positive limit switch' active
W02 Digital input 'Negative limit switch' active
W03 Voltage of mains supply not OK
W04 Power output stage load greater than parameterized warning threshold W04 (power output
stage I²t)
W05 Motor load greater than parameterized warning threshold W05 (motor I²t)
W06 Power output stage temperature greater than parameterized warning threshold W06
W07 Motor temperature greater than parameterized warning threshold W07
W08 DC link voltage greater than parameterized warning threshold W08
W09 DC link voltage less than parameterized warning threshold W09
W10 Speed controller in current limitation / PI limit
Status Display and Error Messages
W
64 Drive Amplifier SD2B / SD2B plus - Hardware Description
