9.4.8 Reassembly: Miscellaneous information
• Position all rating and supplementary plates as in the original state.
• Where relevant, 󹪝x electric cables.
• Check the tightening torques of all screws, as well as those of screws that have not been
released.
9.4.9 Optional add-on units
Note
Further documents
Observe all of the other documents provided with this machine.
You can 󹪝nd additional operating instructions here: AUTOHOTSPOT
9.4.9.1 Mounting a brake
Table 9-5 Assigning standard brakes for 1LE1 machines
Shaft height Brake type Tightening torque for the man‐
ual release lever
Nm
63 INTORQ BFK 458-6 2LM8 005-1NA10 2.8
71 INTORQ BFK 458-6 2LM8 005-2NA10
80 INTORQ BFK 458-8 2LM8 010–3NA10
90 INTORQ BFK 458-10 2LM8 020–4NA10 4.8
100 INTORQ BFK 458-12 2LM8 040–5NA10
112 INTORQ BFK 458-14 2LM8 060–6NA10 12
132 INTORQ BFK 458-16 2LM8 100–7NA10
160 INTORQ BFK 458-20 2LM8 260–8NA10 23
180 INTORQ BFK 458-20 2LM8 315–0NA10
200 INTORQ BFK 458-25 2LM8 400–0NA10 40

225 INTORQ BFK 458-25 2LM8 400–0NA10
Precima FDX 30
250 Pintsch Bubenzer KFB 63
Precima FDX 30
280 Pintsch Bubenzer KFB 100
Precima FDX 40
315 Pintsch Bubenzer KFB 160
Precima FDX 40
Maintenance
9.4Corrective maintenance
1LE1, 1FP1/3, 1PC1/3 shaft height 63 ... 315
112 Operating Instructions, 11/2023, A5E38483075A
