6.3.1 Cable entries, sealing plugs and thread adapters
Note the following when mounting:
• Avoid damaging the cable jacket.
• Adapt the tightening torques to the cable jacket materials.
Observe the documentation for tightening torques of the cable entries and sealing plugs for
direct mounting at the machine as well as additional glands (e.g. adapters).
6.4 Connecting the grounding conductor
The machine's grounding conductor cross-section must comply with EN/IEC60034-1.
Please also observe installation regulations suchas those specied in EN/IEC60204-1.
Basically, there are two ways of connecting a grounding conductor to the machine.
• Internal grounding with a connection in terminal box at the location intended for this
purpose and marked accordingly.
• External grounding with connection at the stator housing at the locations intended for this
purpose and marked accordingly.
6.4.1 Minimum surface area of grounding conductor
Table 6-3 Minimum cross-sectional area of grounding conductor
Minimum cross-section of the phase conductor
for installation
S
mm²
Minimum cross-section of the associated
grounding connection
mm²
S ≤ 25 S
25 < S ≤ 50 25
S>50 0.5 S
Electrical connection
6.4Connecting the grounding conductor
1LE1, 1FP1/3, 1PC1/3 shaft height 63 ... 315
70 Operating Instructions, 11/2023, A5E38483075A
