Danger if the machine falls
The attachment points on the machine are designed for the weight of the machine only. If a
machine set is lifted and transported at a single machine, this can fracture the attachment point.
The machine or machine set may fall. This can result in death, serious injury or material damage.
• Do not lift machine sets by attaching lifting tackle to the individual machines.
• Use only the equipment provided, e.g. the openings or lugs on the base plates, for
transporting machine sets. Note the maximum capacity of the lifting lug.
• Never remain under or in the immediate vicinity of the machine when it is lifted.
WARNING
Danger to life as a result of a machine falling
If the lifting gear or load handling attachments were to fail, the machine could fall. This can
result in death, serious injury or material damage.
• In order to gain easy and safe access to the underside of the machine, place it in a secure
and raised position.
Note
When lifting the machines for transport, only lift them in a position that corresponds to their
basic construction type.
The type of construction of the machine is stated on the rating plate.
4.5.2 Transport
If any transport locks are in place, remove them before commissioning. Store the transport locks
or disable them. Use the transport locks when transporting the motors again or reactivate the
transport locks.
The machines are packed in dierent ways depending on how they are transported and
their size. If not otherwise contractually agreed, the packaging corresponds to the packing
guidelines according to ISPM (International Standards for Phytosanitary Measures).
Comply with the graphic symbols provided on the packaging. Their meaning is as follows:
This
way up
Fragile
goods
Protect
against
moisture
Protect
against
heat
Center of
gravity
Hand hooks
forbidden
Attach
here
Preparing for use
4.5Transport and storage
1LE1, 1FP1/3, 1PC1/3 shaft height 63 ... 315
34 Operating Instructions, 11/2023, A5E38483075A
