Siemens 1FP1/3 User Manual

3.3 Installation
The regulations and standards used as the basis for designing and testing this machine are
stamped on the rating plate. The machine design basically complies with the following
standards:
Table 3-1 Applicable general regulations
Feature Standard EAC
Dimensioning and operating behavior EN/IEC60034-1 GOSTIEC60034-1
Procedure for determining the losses and the e󹪟ciency of rotating electrical
machines and inspections
EN/IEC60034-2-1
EN/IEC60034-2-2
EN/IEC60034-2-3
GOSTIEC60034-2-1
GOSTIEC60034-2-2
GOSTIEC60034-2-3
Degree of protection EN/IEC60034-5 GOSTIEC60034-5
Cooling EN/IEC60034-6 GOSTRIEC60034-6
Type of construction EN/IEC60034-7 GOSTRIEC60034-7
Terminal designations and direction of rotation EN/IEC60034-8 GOST26772
Noise emission EN/IEC60034-9 GOSTIEC60034-9
Integrated thermal protection EN/IEC60034-11 GOST27888
Starting characteristics of rotating electrical machines EN/IEC60034-12 GOSTIEC60034-12
Vibration severity grades EN/IEC60034-14 GOSTIEC60034-14
E󹪟ciency classi󹪝cation of three-phase squirrel-cage induction motors EN/
IEC60034-30-1
GOSTIEC60034-30-1
Rotating electrical machines - Part 30-2: E󹪟ciency classi󹪝cation of variable speed
AC motors (IE-code)
IEC/
TS60034-30-2
GOSTIEC/
TS60034-30-2
IEC standard voltages IEC60038 GOSTRIEC61800-1
3.3.1 Cooling and ventilation
3.3.1.1 General
The machines of this series have a closed primary (internal) cooling circuit and an open
secondary cooling circuit (surface cooling). The surface cooling varies depending on the
version.
Description
3.3Installation
1LE1, 1FP1/3, 1PC1/3 shaft height 63 ... 315
24 Operating Instructions, 11/2023, A5E38483075A
