Part Description Part Description
4.40 Disk 6.03 Bearing cover NDE, inner
5.00 Terminal box, complete 6.10 Rolling bearing
5.02 spacer 6.11 Spring band for end shield hub
5.03 Seal 6.12 Locking ring
5.04 Seal 6.20 End shield
5.06 Mounting rail 6.23 Shaft sealing ring
5.08 Spacer sleeve 6.25 Lubrication sleeve
5.09 Bolt 6.27 Bearing cover NDE, outer
5.10 Complete terminal board 6.29 Bolt
5.11 Terminal block 6.30 Bearing cover NDE, inner
5.13 Link rail 6.31 Flanged nut
5.15 Plug 6.65 Grease nipple
5.16 Spring lock washer 6.66 Screw
5.18 Spring lock washer 6.67 Rubber bush
5.19 Bolt 6.72 Grease slinger
5.21 Screw (drilled) 7.00 Ventilation system, complete
5.24 Bolt 7.04 Fan
5.27 Clamp 7.12 Locking ring
5.28 Upper saddle terminal 7.40 Fan cover
5.29 Lower saddle terminal 7.41 bracket
5.36 Spring lock washer 7.48 Washer
5.37 Spring lock washer 7.49 Bolt
5.42 Terminal box housing, including seal  
Tools for mounting and withdrawing roller bearings; fans and output transmission elements cannot be supplied.
Spare parts
10.7Machine parts
1LE1, 1FP1/3, 1PC1/3 shaft height 63 ... 315
Operating Instructions, 11/2023, A5E38483075A 119
