Administration
25
Step by Step
LAN Port 2 Mode
For detailed information see  Page 79.
Switch to the administration area and choose
"Configuration"
 Page 21.
: Confirm.
>
: Select and confirm.
: Confirm.
or
>
: Select and confirm.
or
>
: Select and confirm.
or
>
: Select and confirm.
or
>
: Select and confirm.
The change is displayed.
LAN Port 2 Enabled
For detailed information see  Page 79.
Switch to the administration area and choose
"Configuration"
 Page 21.
: Confirm.
>
: Select and confirm.
: Confirm.
or
> : Confirm.
The change is displayed.
"LAN Port 2 Mode" is not configurable for
optiPoint
410 entry and optiPoint 410/
420
economy.
01=Network? >
09=LAN port 2 mode? >
Auto >
10 Mb/s half duplex >
10 Mb/s full duplex >
100 Mb/s half duplex >
100 Mb/s full duplex >
01=Network? >
10=LAN port 2 enabled? >
Yes? >
No? >
