Step by Step
Administration
24
QoS Layer Options
For detailed information see  Page 86.
Switch to the administration area and choose
"Configuration"
 Page 21.
: Confirm.
> : Select and confirm.
: Confirm.
or
> : Select and confirm.
or
> : Select and confirm.
or
> : Select and confirm.
The change is displayed.
LAN Port 1 Mode
For detailed information see  Page 79.
Switch to the administration area and choose
"Configuration"
 Page 21.
: Confirm.
>
: Select and confirm.
: Confirm.
or
>
: Select and confirm.
or
>
: Select and confirm.
or
>
: Select and confirm.
or
>
: Select and confirm.
The change is displayed.
01=Network? >
07=QoS L2/L3? >
L2on/L3on >
L2off/L3off >
L2off/L3on >
L2on/L3off >
01=Network? >
08=LAN port 1 mode? >
Auto >
10 Mb/s half duplex >
10 Mb/s full duplex >
100 Mb/s half duplex >
100 Mb/s full duplex >
