Program coordination
Identifier Parameter Explanation
PUTFTOCF INT:
No. of the
function
VAR REAL:
Reference
value
INT: Pa‐
rameter
number
INT:
Channel
number
or
channel
name from
MD20000*
)
Change of fine tool compensation depending
on a function defined with FCTDEF
(max. 3rd degree polynomial)
The number used here must be specified in
FCTDEF
AXTOCHAN 1. 2. 3. - n. 4. - m. Axes transferred to other channels
AXIS:
Axis identifi‐
er
INT:
Channel
number
or
channel
name from
MD20000*
)
As 1 ... As 2 ...
)
Instead of channel numbers, the channel names defined via MD20000 $MC_CHAN_NAME can also be programmed.
**
)
Commands are acknowledged on request from the executing component (channel, NC, etc.).
***
)
The SPI function can be used to program a spindle instead of an axis. E.g. GET(SPI(1))
Data access
Identifier Parameter Explanation
CHANDATA 1. Set channel number for channel data access (only permitted in the initialization block).
The following access refers to the channel set with CHANDATA.
INT:
Channel num‐
ber
NEWCONF Accept changed machine data
Messages
Identifier Parameter Explanation
1. 2.
MSG STRING:
Message
INT:
Execution
Output arbitrary character string as message on the user in‐
terface
WRTPR STRING:
Character string
INT:
Execution
Write string in OPI variable
Tables
4.4 Predefined procedures
NC programming
1278 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
