Synchronous spindle
Identifier Parameter Explanation
1. 2. 3. 4. 5. 6.
COUPOF AXIS:
Follow‐
ing spin‐
dle
AXIS:
Leading
spindle
REAL:
Switch-off
position of
the follow‐
ing spindle
(absolute)
REAL:
Switch-off
position of
the leading
spindle (ab‐
solute)
Switch-off synchro‐
nous spindle coupling
If positions are speci‐
fied, the coupling is on‐
ly cancelled when all
the specified positions
have been overtrav‐
eled
The following spindle
continues to revolve at
the last speed pro‐
grammed before deac‐
tivation of the coupling
COUPOFS AXIS:
Follow‐
ing spin‐
dle
AXIS:
Leading
spindle
REAL:
Switch-off
position of
the follow‐
ing spindle
(absolute)
Switch off the synchro‐
nous spindle coupling
with stop of the follow‐
ing spindle
If a position is speci‐
fied, the coupling is on‐
ly cancelled when the
specified position is
crossed
WAITC AXIS:
Follow‐
ing spin‐
dle
STRING
[8]:
Block
change
behavior
AXIS:
Following
spindle
STRING[8]:
Block
change be‐
havior
Wait until the coupling
block change criterion
for the spindles (max.
2) has been fulfilled
If the block change be‐
havior is not specified,
the block change be‐
havior specified in the
definition with COUP‐
DEF applies
Electronic gear
Identifier Parameter Explanation
EGDEL 1. Delete cou‐
pling defini‐
tion for the fol‐
lowing axis
AXIS:
Follow‐
ing axis
EGDEF 1. 2. / 4. /
6. / 8. /
10.
3. / 5. /
7. / 9. /
11.
Definition of
an electronic
gear
AXIS:
Follow‐
ing axis
AXIS:
Leading
axis
INT:
Coupling
type
Tables
4.4 Predefined procedures
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1283
