1 2 3 4 5 6 7 8 9 10 Default device name
o on on o o o o o pp72x48pn6
on o on o o o o o pp72x48pn5
o o on o o o o o pp72x48pn4
on on o o o o o o pp72x48pn3
o on o o o o o o pp72x48pn2
on o o o o o o o pp72x48pn1
o o o o o o o o pp72x48pn
Note
A newly set PROFINET address will only come into eect after power OFF/ON.
9.3.4.4 X111, X222 and X333 digital inputs/outputs
Cable specication
• Connectors: 50-pin ribbon cable connectors
50-pin insulation displacement connectors with cable grip, ribbon cables and terminal
converters
are required for connecting digital inputs and outputs.
• The required connecting cables (ribbon cables) must be provided by the user
.
• Max. cable length: 30 m
Pin assignment
Table 9-42 Pin assignment X111
Pin Signal name Type Pin Signal name Type
1 M GND 2 P24OUT VO
3 DI 0.0 I 4 DI 0.1 I
5 DI 0.2 I 6 DI 0.3 I
7 DI 0.4 I 8 DI 0.5 I
9 DI 0.6 I 10 DI 0.7 I
11 DI 1.0 I 12 DI 1.1 I
13 DI 1.2 I 14 DI 1.3 I
15 DI 1.4 I 16 DI 1.5 I
17 DI 1.6 I 18 DI 1.7 I
19 DI 2.0 I 20 DI 2.1 I
21 DI 2.2 I 22 DI 2.3 I
23 DI 2.4 I 24 DI 2.5 I
25 DI 2.6 I 26 DI 2.7 I
27 Not assigned - 28 Not assigned -
Connectable components
9.3 PP 72/48D 2/2A PN
NCU 7x0.3B PN
128 Equipment Manual, 10/2020, 6FC5397-1EP40-6BA1
