1 2 3 4 5 6 7 8 9 10 Default device name
on on on o on on on o pp72x48pn119
o on on o on on on o pp72x48pn118
on o on o on on on o pp72x48pn117
o o on o on on on o pp72x48pn116
on on o o on on on o pp72x48pn115
o on o o on on on o pp72x48pn114
on o o o on on on o pp72x48pn113
o o o o on on on o pp72x48pn112
x x x x x x x x "
on on on on o o o o pp72x48pn15
o on on on o o o o pp72x48pn14
on o on on o o o o pp72x48pn13
o o on on o o o o pp72x48pn12
on on o on o o o o pp72x48pn11
o on o on o o o o pp72x48pn10
on o o on o o o o pp72x48pn9
o o o on o o o o pp72x48pn8
on on on o o o o o pp72x48pn7
o on on o o o o o pp72x48pn6
on o on o o o o o pp72x48pn5
o o on o o o o o pp72x48pn4
on on o o o o o o pp72x48pn3
o on o o o o o o pp72x48pn2
on o o o o o o o pp72x48pn1
o o o o o o o o pp72x48pn
Note
A newly set PROFINET address will only come into eect after power OFF/ON.
9.2.3.4 X111, X222 and X333 digital inputs/outputs
Cable specication
• Connectors: 50-pin ribbon cable connectors
50-pin insulation displacement connectors with cable grip, ribbon cables and terminal
converters
are required for connecting digital inputs and outputs.
• The required connecting cables (ribbon cables) must be provided by the user
.
• Max. cable length: 30 m
Connectable components
9.2 PP 72/48D PN
NCU 7x0.3B PN
Equipment Manual, 10/2020, 6FC5397-1EP40-6BA1 109
