9.5.3 Connection
Properties
The X1400 interface has full-duplex 10/100-Mbit Ethernet ports with autocrossing. The module
has an integrated 4-port switch.
Interface characteristics
Table 9-72 X1400
Characteristic Version
Connector type RJ45 socket*)
Cable type Industrial Ethernet cable (CAT5)
Max. cable length 100 m
*) Please use the Fast Connect connector as described in Chapter "PROFINET cables (Page 62)".
Pin assignment
Table 9-73 X1400 interface, ports 1 - 4
Pin Signal name Signal type Meaning
1 TX+ Output Transmit data +
2 TX- Output Transmit data -
3 RX+ Input Receive data +
4 NC
5 NC
6 RX- Input Receive data -
7 NC
8 NC
Connectable components
9.5 CBE30-2
NCU 7x0.3B PN
Equipment Manual, 10/2020, 6FC5397-1EP40-6BA1 153
