Issue 01/05 Data transfer using CANopen
CANopen Option Module Operating Instructions
6SE6400-5BC00-0BP0
51
Optimizing EMERGENCY telegrams
In order to better handle Emergency telegram that are sent non-synchronously
when high bus load levels exist, there are various optimization methods.
Emergency messages can be suppressed by setting bit 31 in object 1014H (COB-
ID EMCY). Then, faults that occur are only displayed in the status word and can be
read-out of object 1003H.
Object 1014H also allows the COB-ID to be changed, which can then be used to
modify the priority of the message. Using the object 1015H (Inhibit Time EMCY), it
is possible to set a delay time for sending the EMCY message.
MICROMASTER 420/430/440 sends an Emergency message if an fault has
occurred in either the option module or in the inverter.
Table 3-13 EMERGENCY messages that are not generated by the drive
Error Code
(Bytes 1/ 2)
(Hex)
Meaning Additional
code
(Bytes 3/4)
Description
6300H Dataset update failed 1 Failed to change to new drive dataset. Further
information in diagnostic parameter P2054[0].
Note that this message does not have a
corresponding reset-emergency message!!!
7600H ResetCommunication
or
ResetNode failed
2 Tried to execute ResetNode, or ResetCommunication
after data has been saved to EEPROM.
Note that this message does not have a
corresponding reset-emergency message!!!
7600H ResetCommunication
or
ResetNode not possible
2 ResetNode, or resetCommunication failed. Further
information in diagnostic parameter P2054[0].
Note that this message does not have a
corresponding reset-emergency message!!!
8000H CAN sync error 0 CAN sync object not received within communication
cycle period 1006H x 1.5
8000H Drive running 1 Tried to execute ResetNode, or ResetCommunication
whilst drive running.
Note that this message does not have a
corresponding reset-emergency message!!!
8110H CAN overrun 0 Data Overrun has occurred
(unable to process data before next message arrived).
8130H CAN lifeguarding failure 0 RTR frame was not received within the time: Node
Guard time x Node Lifetime factor
8140H Busoff cleared 0 Busoff condition has been cleared.
Note that this message does not have a
corresponding reset-emergency message!!!
