Siemens MICROMASTER 440 Series User Manual

International English 4 Using the MICROMASTER 440
MICROMASTER 440 Operating instructions
6SE6400-5CA00-0BP0
45
4 Using the MICROMASTER 440
This Chapter contains:
 An explanation of the various methods of controlling the inverter
 An outline of some of the more commonly used parameters of the
MICROMASTER 440 which will allow the user to configure the inverter for a
number of applications.
 A brief summary of all the inverter’s control modes and an introduction to the
inverter’s fault and warning reporting capability.
 More detailed information can be found in the Parameter List and the
Reference manual associated with the MICROMASTER 440.
4.1 Frequency Setpoint (P1000) ................................................................................... 46
4.2 Command Sources (P0700).................................................................................... 47
4.3 OFF and braking Functions..................................................................................... 47
4.4 Control Modes (P1300) ........................................................................................... 49
4.5 Faults and warnings ................................................................................................ 50
http://nicontrols.com

Siemens MICROMASTER 440 Series Specifications

General

Power Range	0.12 kW to 250 kW
Output Voltage	0V to Input Voltage
Frequency Range	0 Hz to 650 Hz
Overload Capacity	150% for 60 seconds, 200% for 3 seconds
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Control Modes	Vector control
Protection Features	Overvoltage, undervoltage, short circuit
Communication Interfaces	PROFIBUS, CANopen, RS485
Operating Temperature	-10°C to +50°C
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
