Page 4 Milltronics BW100 - INSTRUCTION MANUAL 7ML19985DJ01
mmmmm
Specifications
Inputs
• load cell: 0 - 45 mV dc per load cell
• speed sensor: pulse train: 0-5 V low, 5-15 V high, 1 to 2000 Hz,
or
open collector switch
or
relay dry contact
• auto zero: dry contact from external device
Outputs
• analog: - optically isolated 0/4 - 20 mA
- 750
Ω max loading
• resolution: - 0.1% of 20 mA
• load cell: - 10 Vdc compensated for strain gauge type, 2 cells max
• speed sensor: - 12 Vdc, 50 mA max excitation
• remote totalizer 1: - contact closure 32 - 288 ms duration
- open collector switch rated 30 Vdc, 100 mA max
• remote totalizer 2: - contact closure 32 - 288 ms duration
- open collector switch rated 240 Vac/dc, 100 mA max
• relay output: programmable function 1 form C SPDT relay contact rated
5 A at 250 Vac, non-inductive
Communications
• Dolphin compatible
• proprietary bipolar current loop
Cable/Separation:
• one load cell/LVDT:
non-sensing: Belden 8404, 4 wire shielded, 20 AWG or equivalent,
150 m (500 ft.) max.
sensing: Belden 9260, 6 wire shielded, 20 AWG or equivalent,
300 m (1000 ft.) max.
• two load cells:
non-sensing: Belden 9260, 6 wire shielded, 20 AWG or equivalent,
150 m (500 ft.) max.
sensing: Belden 8418, 8 wire shielded, 20 AWG or equivalent,
300 m (1000 ft.) max.
• speed sensor Belden 8770, 3 wire shielded, 18 AWG or equivalent,
300 m (1000 ft.) max.
• auto zero: Belden 8760, 1 pair, twisted/shielded, 18 AWG, 300 m
(1000 ft.) max.
• remote total: Belden 8760, 1 pair, twisted/shielded, 18 AWG, 300 m
(1000 ft.) max.
