Specifications
Specifications
Power
• standard: 100/115/200/230 Vac ± 15%, 50/60 Hz, 15VA
• optional: 10 - 15 V dc, 15 W
18 - 30 V dc, 15 W
Application
• compatible with Siemens Milltronics belt scales or equivalent
Accuracy
• 0.1% of full scale
Resolution
• 0.02% of full scale
Environmental
• location: indoor / outdoor
• altitude: 2000 m max
• ambient temperature: -20 to 50 °C (-5 to 122 °F)
• relative humidity: suitable for outdoor
• installation category: II
• pollution degree: 4
Enclosure
• polypropylene alloy
• Type 4X / NEMA 4X / IP 65
• sealed electronics compartment
• integral junction box with termination block for 0.2 - 4 mm solid or
0.2 - 2.5 mm stranded (12 - 24 AWG)
Programming
• via local 4 member keypad with silicone boot and/or Dolphin interface
Display
• 38 x 100 mm (1.5 x 4") multi-field liquid crystal display
Memory
• program stored in non-volatile FLASH memory, upgradable via Dolphin interface
• parameters stored in non-volatile EEPROM
