Siemens Prisma 3T User Manual

Revision Date: 3/13/2019
15
Register the Phantom
1. Press the “little person” key on the keyboard to bring up the registration screen
2. Enter phantom information (all required fields are indicated in bold except required data
destination= Referring physician)
 Last Name = ABCDPhantom017_32CH or ABCDPhantom017_64CH
 Patient ID = copy the information from the Last Name field to the Patient ID
field.
 Sex = “other”
 Age = “18”
 Height = “5ft”
 Weight = “100 lbs”
 Referring Physician = select “ABCDPHANTOMGROUP”
 Patient Position = select “Head First Supine”
3. Click “Exam”
4. Another box will pop up
 Under ABCD choose the appropriate protocol:
o ABCD_QA_full__32ch (29:04min)
o ABCD_QA_quick__32ch (15:36min)
o ABCD_QA_full__64ch (29:04min)
o ABCD_QA_quick__64ch (15:36min)
 Click “Confirm”
