Chapter 2
Installing the Device
RUGGEDCOM RX1400
Installation Guide
20 Inserting/Removing the MicroSD Card
4. Once the device is fully installed, activate the micro-SIM cards for the LTE modem. For more information, refer
to the RUGGEDCOM ROX II User Guide for the RUGGEDCOM RX1400.
Section2.8
Inserting/Removing the MicroSD Card
The RUGGEDCOM RX1400 accepts a microSD card for storing configuration files and/or software updates.
CAUTION!
Configuration hazard – risk of data loss. The microSD card must not be removed or replaced during
normal operation of the device. Make sure the device is powered down before removing or inserting
the card.
CAUTION!
Mechanical/electrical hazard – risk of damage to the microSD card.
• Do not expose the microSD card to extreme temperatures or humidity.
• Do not expose the microSD card to large magnetic or static electric fields.
• Do not bend or drop the microSD card.
CAUTION!
Security hazard – risk of unauthorized access and/or exploitation. Make sure to remove the microSD
card before decommissioning the device or sending the device to a third-party.
To insert or remove a microSD card, do the following:
1. Power down the device.
2. Disconnect all network, alarm and console cables.
3. Unscrew the retention screw and remove the access plate.
Figure10:Inserting/Removing a MicroSD Card
1.MicroSD Card 2.Access Plate
4. Without touching the contacts on the card, insert or remove the microSD card.
5. Install the access plate and finger-tighten the retention screw.
6. Power up the device.
