RUGGEDCOM RX1400
Installation Guide
Chapter 6
Certification
EMC and Environmental Type Tests 51
Test Description Test Levels
DC Power Ports
Signal PortsDielectric Strength
DC Power Ports
2828 VDC or 2 kV
Signal Ports
DC Power Ports
Fast Transient (SWC)
Earth Ground Ports
± 4 kV @ 2.5 kHz, 5 kHz
Signal Ports 2.5 kV Common mode @1 MHzOscillatory (SWC)
DC Power Ports 2.5 kV Common Mode
1 kV Differential Mode @ 1 MHz
Radiated RFI Enclosure ports 35 V/m
Enclosure Contact ± 8 kVESD
Enclosure Air ± 15 kV
IEEE 1613.1/
IEC 61000-4-10
Damped Oscillating
Magnetic Field
Enclosure Ports 100 A/m for 1 s (100 kHz and 1 MHz)
Environmental Type Tests
Test Description Test Levels
Cold Temperature Test Ad -40 °C (-40 °F), 16 HoursIEC 60068-2-1
Cold Storage Test Ab -40 °C (-40 °F), 16 hours
Dry Heat Test Bd 85 °C (185 °F), 16 HoursIEC 60068-2-2
Dry Heat Storage Test Bb 85 °C (185 °F), 16 hours
IEC 60068-2-30 Humidity (Damp Heat, Cyclic) Test Db 95% (Non-Condensing), 55 °C (131 °F), 6 cycles
IEC 60068-78 Humidity (Damp Heat, Steady State) 10 days @ 55 °C (131 °F)
and 93% Relative Humidity
IEC 60255-21-1 Vibration 2 g @ 10-150 Hz
IEC 60255-21-2 Shock 30 g @ 11 ms
IEC 60255-21-3 Seismic Method A, Class 2
IEC 60068-1-14 Change of Temperature 5 Cycles (-40 to 85 °C or -40 to 185 °F)
