Chapter 4
Technical Specifications
RUGGEDCOM RX1400
Installation Guide
34 Operating Environment
Host Interface 4-Bit SDIO
Maximum EIRP < 200 mW at 5250 to 5350 MHz
Section4.7
Operating Environment
The RUGGEDCOM RX1400 can operate under the following environmental conditions:
Parameter Range Comments
Ambient Operating Temperature -40 to 85 °C
(-40 to 185 °F)
j
Measured from a 30 cm (12 in) radius surrounding the center of the
enclosure.
Ambient Relative Humidity 5% to 95% Non-condensing
Ambient Storage Temperature -40 to 85 °C
(-40 to 185 °F)
j
Maximum ambient operating temperature is 70 °C (158 °F) when the device is installed along with Underwriter Laboratories (UL) listed devices.
Section4.8
Mechanical Specifications
Dimensions Refer to Chapter5, Dimension Drawings
Weight 2.5 kg (5.5 lb)
Ingress Protection IP40
Enclosure Aluminum
