RUGGEDCOM RX1400
Installation Guide
Chapter 4
Technical Specifications
WLAN Specifications 33
Acquisition Time • Hot start: 1 s
• Warm start: 29 s
• Cold start: 32 s
Accuracy • Horizontal: < 2 m 6.6 ft (50 %), < 5 m or 16.4 ft (90 %)
• Altitude: < 4 m or 13.1 (50 %), < 8 m or 26.2 (90 %)
• Velocity: < 0.2 m/s or 0.7 ft/s
Sensitivity • Tracking: -161 dBm
• Acquisition (Assisted, Non-LTE): -158 dBm
• Acquisition (Assisted, LTE): -153 dBm
• Acquisition (Standalone): -145 dBm
Operational Limits Altitude < 6000 m (3.7 mi) or velocity < 100 m/s (328 ft/s)
g
g
Either limit may be exceeded, but not both
GNSS Standalone Antenna Requirements
Frequency Range • Narrow-band GPS: 1572.42 MHz ± 2 MHz minimum
• Wide-band GPS and GLONASS: 1565 to 1606 MHz recommended
Field of View (FoV) • Omni-directional in azimuth
• -45° to 90° in elevation
Polarization (average Gv/Gh) > 0 dB
h
Free space average gain (Gv+Gh) over FoV > -3 (preferred) or -6 dBi
i
Gain • Maximum gain and uniform coverage in the high elevation angle and zenith
• Gain in azimuth plane is not desired
Average 3D gain > -5 dBi
Isolation between GNSS and LTE Main
(Primary)
> 10 dB in all uplink bands
Typical VSWR < 2:5:1
Polarization Any other than LHCP (Left-Hand Circular Polarized) is acceptable.
h
Vertical linear polarization is sufficient.
i
Gv and Gh are measured and averaged over -45 to 90° in elevation, and ± 180° in azimuth.
Section4.6
WLAN Specifications
Supported Standards IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Maximum Throughput TCP: 80 Mbps at 2.4 GHz
UDP: 100 Mbps at 2.4 GHz
Diversity 2.4 GHz MRC support for extended range
5.0 GHz diversity capable
