6.2 Applying the supply voltage
54 Equipment Manual, 09/2022, L1V30415168B-03
6.2 Applying the supply voltage
A supply voltage is required to operate the device. Please consult the technical data or the
rating plate for the type and level of the possible supply voltage.
Refer also to the diagram Connections (Page 34) and Safety instructions
The wrong system connection can damage the device.
Failure to heed this warning can result in damage to the device and the system. The
minimum and maximum limits given in the technical data and on the rating plate must not
be exceeded even during startup or testing of the device.
6.3 Parameterizing the device
Procedure
The device is configured using the powerconfig configuration software (from version V3.7)
via the Ethernet interface.
You can download the powerconfig configuration software from the Industry Online Support
Website (https://sie.ag/3aHK6bu
).
Information and notes on how to use powerconfig can be found in the Online Help of the
configuration software or by contacting Technical Support.
You launch the Online Help in powerconfig by pressing the "F1" key.
To start up the device, you must specify the operating parameters listed below in the device
settings:
• Connection type
• Ethernet parameter
• Voltage
– Direct measurement on the system or using voltage transformers
– Measuring input voltage in the case of direct measurement on the system
– Primary and secondary voltage when measuring using voltage transformers
• Current
– Primary current
