Address Min/Max Value Parameters Unit Type
1013 0 to 3599 Phase angle I
3
1/10° uInt16
1014 0 to 3599 Phase angle I
N
1/10° uInt16
1015 0 to 3599 Phase angle V
12
1/10° uInt16
1016 0 to 3599 Phase angle V
23
1/10° uInt16
1017 0 to 3599 Phase angle V
31
1/10° uInt16
1018 0 to 3599 Phase angle V
1
1/10° uInt16
1019 0 to 3599 Phase angle V
2
1/10° uInt16
1020 0 to 3599 Phase angle V
3
1/10° uInt16
1021 0 to 3599 Phase angle V
NG
1/10° uInt16
1022,
1027,
1031
0 to 65535 Apparent power phase 1, apparent power
phase 2, apparent power phase 3
1/10 kVA for 230-V
sensor
uInt16
1 kVA for 3.25/√3
sensor, for 100/√3
sensor, and for 400/√3
sensor
1023,
1028,
1032
-32768 to 32767 Active power phase 1, active power phase
2, active power phase 3
1/10 kW for 230-V
sensor
sInt16
1 kW for 3.25/√3
sensor, for 100/√3
sensor, and for 400/√3
sensor
1024,
1029,
1033
-32768 to 32767 Reactive power phase 1, reactive power
phase 2, reactive power phase 3
1/10 kVAr for 230-V
sensor
sInt16
1 kVAr for 3.25/√3
sensor, for 100/√3
sensor, and for 400/√3
sensor
1025,
1030,
1034
-1000 to 1000 Power factor phase 1, power factor phase 2,
power factor phase 3
1/1000 sInt16
1026 0 to 65535 Frequency 1/100 Hz uInt16
1035,
1036,
1037
Dir A, Dir B Power-flow direction of phase I
1
, power-
flow direction of phase I
2
, power-flow direc-
tion of phase I
3
–
1038 -32768 to 32767 3-phase active power 1/10 kW for 230-V
sensor
sInt16
1/100 MW for 3.25/√3
sensor, for 100/√3
sensor, and for 400/√3
sensor
1039 -32768 to 32767 3-phase reactive power 1/10 kVAr for 230-V
sensor
sInt16
1/100 MVAr for 3.25/
√3 sensor, for 100/√3
sensor, and for 400/√3
sensor
Modbus Registers
B.2 Implementation of the Modbus Protocol
