Address Min/Max Value Parameters Unit Type
1055 0 to 65535 Boot-loader major and maintenance version
number
– uInt16
1056 0 to 65535 Boot-loader firmware and build version
number
– uInt16
1057 0 to 65535 Ground-fault status register – uInt16
1058 0 to 65535 Phase current I
1
1/10 A uInt16
1059 0 to 65535 Phase current I
2
1/10 A uInt16
1060 0 to 65535 Phase current I
3
1/10 A uInt16
1061 0 to 65535 Ground current I
N
1/10 A uInt16
For more information about register-type data - analog input registers, see B.6 Register-Type Data – Analog
Input Registers.
Table B-7 Analog Input Registers
Address Min/Max Value Parameters Unit Type
1 – Last reset type – uInt16
2 0 to 59999 Last reset time (milliseconds) ms uInt16
3 0 to 23
0 to 59
Last reset time (hours and minutes) h and min uInt16
4 1 to 12
1 to 31
Last reset time (month and date) month and date uInt16
5 12 to 99 Last reset time (year) year uInt16
6 – Overvoltage alarm type – uInt16
7 – Overvoltage alarm time (milliseconds) ms uInt16
8 – Overvoltage alarm time (hours and
minutes)
h and min uInt16
9 – Overvoltage alarm time (month and date) month and date uInt16
10 – Overvoltage alarm time (year) year uInt16
11 – Overvoltage warning type – uInt16
12 – Overvoltage warning time (milliseconds) ms uInt16
13 – Overvoltage warning time (hours and
minutes)
h and min uInt16
14 – Overvoltage warning time (month and date) month and date uInt16
15 – Overvoltage warning time (year) year uInt16
16 – Undervoltage alarm type – uInt16
17 – Undervoltage alarm time (milliseconds) ms uInt16
18 – Undervoltage alarm time (hours and
minutes)
h and min uInt16
19 – Undervoltage alarm time (month and date) month and date uInt16
20 – Undervoltage alarm time (year) year uInt16
21 – Undervoltage warning type – uInt16
22 – Undervoltage warning time (milliseconds) ms uInt16
23 – Undervoltage warning time (hours and
minutes)
h and min uInt16
24 – Undervoltage warning time (month and
date)
month and date uInt16
25 – Undervoltage warning time (year) year uInt16
26 – Overcurrent alarm type – uInt16
Modbus Registers
B.2 Implementation of the Modbus Protocol
SICAM, Feeder Condition Monitor, Manual 103
E50417-H8940-C580-A4, Edition 03.2019
