Bit 15 14 13 12 11 10 9 8
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 16-bit unsigned integer
Range 0 to 3
0 = AC 3.25/√3 V
1 = AC 100/√3 V
2 = AC 230 V
3 = AC 400/√3 V
Default 0 = AC 3.25/√3 V
Date Type
(Address 19) This register defines the date type.
Bit 15 14 13 12 11 10 9 8
Not used Not used Not used Not used Not used Not used Not used Not used
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Not used Not used Not used Not used Not used Date type Date type
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 2-bit unsigned integer
Range 0 = DD-MM-YYYY
1 = MM-DD-YYYY
2 = YYYY-MM-DD
Default 0 = DD-MM-YYYY
Time Type
(Address 20) This register defines the time type.
Bit
15 14 13 12 11 10 9 8
Not used Not used Not used Not used Not used Not used Not used Not used
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Not used Not used Not used Not used Not used Not used Not used Time type
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
Format 1-bit unsigned integer
Range 0 = 12 hour format
1 = 24 hour format
Default 0 = 12 hour format
V
Max
Alarm
(Address 21) This register defines the maximum threshold voltage you can set for providing an alarm. It is
expressed in percentage (%) of the primary voltage.
Bit
15 14 13 12 11 10 9 8
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
Bit 7 6 5 4 3 2 1 0
Modbus Registers
B.4 Register-Type Data – Holding Registers
