Design of the side
The following 󹪝gure shows the left side of the CPU module:
① Fixing screw
② Nameplate (Page 22)
System overview
3.3 Basic components of the system
CN 4100 Communication System
Equipment Manual, 10/2021, A5E50871363-AA 15
