6.4 Supply of the rack
6.4.1 Connections of the rack
The rack has the following connections:










① X1 RJ45 Ethernet port
② X1.1
③ X1.2
④ X2.2
⑤ X2.1
⑥ X2
⑦ PS2 Power supply connection
⑧ EXT2 USB 3.0 port
⑨ EXT1
⑩ PS1 Power supply connection
6.4.2 Notes on the internal wiring of the rack
De󹪝nition
The internal wiring in the rack is shown in the following 󹪝gures.
X1 RJ45 Ethernet port
X1.1
X1.2
X2.2
X2.1
X2
PS1 Power supply connection
PS2
Connecting
