Technical data
16.1 Technical specifications of CPU 410-5H; (6ES7410-5HX08-0AB0)
CPU 410 Process Automation/CPU 410 SMART
System Manual, 05/2017, A5E31622160-AC
255
Article number
6ES7410-5HX08-0AB0
S7 times
• Number
2 048
Data areas and their retentivity
retentive data area in total Total working and load memory (with backup
battery)
Address area
I/O address area
• Inputs
16 kbyte; max., dependent on the System Ex-
pansion Card used
• Outputs
16 kbyte; max., dependent on the System Ex-
pansion Card used
of which distributed
– DP interface, inputs
6 kbyte; max., dependent on the System Expan-
sion Card used
– DP interface, outputs
6 kbyte; max., dependent on the System Expan-
sion Card used
– PROFINET interface, inputs
8 kbyte; max., dependent on the System Expan-
sion Card used
– PROFINET interface, outputs
8 kbyte; max., dependent on the System Expan-
sion Card used
Digital channels
• Inputs
131 072; max., dependent on the System Expan-
sion Card used
• Outputs
131 072; max., dependent on the System Expan-
sion Card used
Analog channels
• Inputs
8 192; max., dependent on the System Expan-
sion Card used
• Outputs
8 192; max., dependent on the System Expan-
sion Card used
Hardware configuration
Number of expansion units, max.
21; S7-400 expansion devices
connectable OPs
119
Multicomputing
No
Interface modules
• Number of connectable IMs (total), max.
6
• Number of connectable IM 460s, max.
6
• Number of connectable IM 463s, max.
4; Single mode only
Number of DP masters
• integrated
1
• via CP
10; CP 443-5 Extended
Number of IO Controllers
• integrated
2
