Technical data
16.1 Technical specifications of CPU 410-5H; (6ES7410-5HX08-0AB0)
CPU 410 Process Automation/CPU 410 SMART
262 System Manual, 05/2017, A5E31622160-AC
Article number
6ES7410-5HX08-0AB0
Alarm 8-blocks
Yes
• Number of instances for alarm 8 and S7
communication blocks, max.
10 000
• preset, max.
10 000
Process control messages
Yes
Test commissioning functions
Status block
Yes
Single step
Yes
Number of breakpoints
4
Status/control
• Status/control variable
Yes
• Variables
Inputs/outputs, memory bits, DBs, distributed
I/Os, timers, counters
• Number of variables, max.
70
Diagnostic buffer
• present
Yes
• Number of entries, max.
3 200
Service data
• can be read out
Yes
Standards, approvals, certificates
CE mark
Yes
CSA approval
Yes
UL approval
Yes
cULus
Yes
FM approval
Yes
RCM (formerly C-TICK)
Yes
KC approval
Yes
EAC (formerly Gost-R)
Yes
Use in hazardous areas
• ATEX
ATEX II 3G Ex nA IIC T4 Gc
Ambient conditions
Ambient temperature during operation
• min.
0 °C
• max.
70 °C
Configuration
Know-how protection
• User program protection/password protec-
tion
Yes
• Block encryption
Yes; With S7 block Privacy
