Siemens SIMATIC CPU 410

Properties and technical specifications of CPU 410 SMART
17.2 Technical specifications of the CPU 410 SMART; (6ES7 410-5HN08-0AB0)
CPU 410 Process Automation/CPU 410 SMART
292 System Manual, 05/2017, A5E31622160-AC
Article number
6ES7410-5HN08-0AB0
– IO Devices changing during operation
(partner ports), supported
No
– Device replacement without swap me-
dium
Yes
– Send cycles
250 µs, 500 µs, 1 ms, 2 ms, 4 ms
– Updating time
250 µs to 512 ms, minimum value depends on
the number of configured user data and the con-
figured single or redundant mode
Address area
– Inputs, max.
1 536 byte; Up to 1 500 IOs (channels)
– Outputs, max.
1 536 byte; Up to 1 500 IOs (channels)
– User data consistency, max.
1 024 byte
Open IE communication
• Number of connections, max.
118
• Local port numbers used at the system end
0, 20, 21, 25, 102, 135, 161, 34962, 34963,
34964, 65532, 65533, 65534, 65535
• Keep-alive function, supported
Yes
4. Interface
Interface type
Pluggable synchronization submodule (FO)
Plug-in interface modules Synchronization module 6ES7960-1AA06-0XA0,
6ES7960-1AB06-0XA0 or 6ES7960-1AA08-0XA0
5. Interface
Interface type
Pluggable synchronization submodule (FO)
Plug-in interface modules Synchronization module 6ES7960-1AA06-0XA0,
6ES7960-1AB06-0XA0 or 6ES7960-1AA08-0XA0
Protocols
Supports protocol for PROFINET IO
Yes
PROFINET CBA
No
PROFIsafe
No
PROFIBUS
Yes
AS-Interface
Yes; Via add-on
Protocols (Ethernet)
• TCP/IP
Yes
Further protocols
• Foundation Fieldbus
Yes; via DP/FF Link
• MODBUS
Yes; Via add-on
Communication functions
PG/OP communication
Yes
• Number of connectable OPs without mes-
sage processing
119
• Number of connectable OPs with message
processing
119; When using Alarm_S/SQ and Alarm_D/DQ
