Supplementary information
18.16 CPU 410 cycle and reaction times
CPU 410 Process Automation/CPU 410 SMART
360 System Manual, 05/2017, A5E31622160-AC
K+ portion in the central controller (from row A in the following table)
+ portion in the expansion device with local connection (from row B)
+ portion in the expansion device with remote connection (from row C)
+ portion via integrated DP interface (from row D1)
+ portion via external DP interface (from row D2)
portion of consistent data via integrated DP interface (from row E1)
+ portion of consistent data via external DP interface (from row E2)
+ portion in PN/IO area for the integrated PROFINET IO interface (from row F)
+ portion for each submodule with 32 byte of consistent data for the integrated PROFINET
IO interface (from row G)
= Transfer time for process image update
The tables below show the various portions of the transfer time for a process image update
(process image transfer time). The specified times only represent "ideal values", and may be
extended accordingly by any interrupts or communication of the CPU.
Table 18- 11 Portion of the process image transfer time, CPU 410-5H
Portions
CPU 410-5H
stand-alone mode
CPU 410-5H
redundant
K
Base load
2 µs
3 µs
A
*)
In the central controller
Read/write byte/word/double word
7.3 µs
15 µs
B
*)
In the expansion unit with local link
Read/write byte/word/double word
20 µs
26 µs
C
*)**)
In the expansion unit with remote link
Read/write byte/word/double word 45 µs 50 µs
D1 In the DP area for the integrated DP interface
Read byte/word/double word
0.4 µs
10 µs
D2
***)
In the DP area for the external DP interfaces
Read/write byte/word/double word
5 µs
15 µs
E1 Consistent data in the process image for the integrated DP
interface
Read/write data
8 µs
30 µs
E2 Consistent data in the process image for the external DP
interface (CP 443–5 extended)
Read
write
80 µs
60 µs
100 µs
70 µs
F In the PNIO area for the integrated PROFINET IO interface
Read/write for each byte/word/double word
2 µs 15 µs
G Per submodule with 32 bytes of consistent data for the inte-
grated PROFINET IO interface
8 µs 30 µs
*)
In the case of I/O inserted into the central controller or expansion device,
the specified value includes the execution time for the I/O module
The module data is updated with the minimum number of accesses.
(example: 8 bytes result in 2 double word accesses; 16 bytes in 4 double word accesses.)
**)
Measured with IM460-3 and IM461-3 at a link length of 100 m
***)
Measured with modules with 1 byte of user data, e.g., DI 16.
