Commissioning
6.2 PROFINET IO
ET 200M
98 Operating Instructions, 12/2008, EWA-4NEB780600602-08
6.2.3 Assigning device names to the I/O device
Introduction
Each PROFINET IO device is assigned a unique device ID at the factory (MAC address).
For configuration and in the user program, each ET 200M IO device is addressed with its
device name.
For detailed information on addressing in PROFINET IO, refer to the "PROFINET System
Description (http://support.automation.siemens.com/WW/view/en/19292127
)" system
manual.
Requirements
● Interface Module IM 153-4 PN
● up to IM 153-4AA00-0XB0: SIMATIC Micro Memory Card 64k and higher
● The programming device must be online on PROFINET to the IO device to let you assign
a device name to the interface module.
● The IO device is configured in HW Config and assigned an IP address.
Assigning device names
1. For IM 153-4AA00-0XB0:
Insert an empty SIMATIC Micro Memory Card into the module slot on the front of the
IM 153-4 PN interface module.
2. Switch on the voltage supply for the IM 153-4 PN.
3. In HW Config, open the "Properties - IM 153-4 PN" window, enter the device name for the
IO device, and then confirm your entry with "OK".
Do not use the device name "noname".
Transferring the device name to the interface module.
1. In HW Config, select "PLC > Ethernet > Assign Device Name".
2. Click "Assign Name" in the "Assign Device Name" window.
Result
The device name is saved on the SIMATIC Micro Memory Card in the IM 153-4AA00-0XB0
interface module.
As of IM 153-4AA01-0XB0, the device name is saved in the interface module.
