Compatibilities between the IM 153-x
A
This chapter includes the most important information that you must know if you are
"changing over" from an old IM 153-x to a new or different IM 153-x.
A.1 Compatibilities between the versions of IM 153 and IM 153-1
The versions of IM 153-1
Table A- 1 Properties and variants of the IM 153-1
Interface module with order number
6ES7153-1AA..
Functions / properties
00 01 02 03 82 83
Min_slave_interval between two slave list cycles 1 ms 0,1 ms 0,1 ms 0,1 ms 0,1 ms 0,1 ms
SYNC, FREEZE – x x x x x
Module change during operation – – x x – –
Direct data exchange – – as of E07 x as of E06 x
Enhanced diagnostics
• 64 byte diagnostic frame
– – – x
as of E02
– x
Extended range of environmental conditions
(outdoors)
– – – – x x
RC network with 10 MΩ for unearthed configuration -
(1 MΩ)
-
(1 MΩ)
as of E08 x as of E07 x
DPV1-mode – – – as of E05 – as of E03
E = module version
Compatibility between 153-1AA00- and 153-1AA01-…
The IM 153-1, order number 6ES7153-1AA01-0XB0 is partially upwards compatible. This
means that the configuration and the user programs for the IM 153-1, order number
6ES7153-1AA01-0XB0 can also be used for the IM 153, order number
6ES7153-1AA00-0XB0, apart from if you are working with SYNC and FREEZE in these user
programs. Note also the different min_slave-intervals (refer to table above).
Retrofitting to 153 1AA02 ...
The IM 153-1 with order number 6ES7153-1AA01-0XB0 can be retrofitted to the IM 153-1
with order number 6ES7153-1AA02-0XB0.
Contact your Siemens representative for this.
