Assignment planning
3
3.1 Structure variants for PROFIBUS DP
With the IM 153-2Bxx1 you can set up an ET 200M with any input / output module.
The IM 153-2Bxx1 is also a spare part for the IM 153-2 (6ES7153-2xxxx-0XB0).
In addition, the IM 153-2Bxx1 can be used as an interface module for the DP/PA-link or the
Y-link. You will find additional information in the "DP/PA Link and Y Link bus links
(http://support.automation.siemens.com/WW/view/en/1142696
)" operating instructions.
Structure variants in the non-outdoor area
Using the existing hardware you can realize the combinations listed in the following table in
the non-outdoor area.
Table 3- 1 ET 200M structure variants in the non-outdoor area
non-redundant configuration redundant configuration
• IM 153-2 + bus connector
+ I- / O-modules
• BM PS/IM + PS + IM 153-2
+ BM 2 x 40 / BM 1 x 80 + I- / O-modules
• BM IM/IM (7HD10 / 7HD80) + IM 153-2
+ BM 2 x 40 / BM 1 x 80 + I- / O-modules
• BM IM/IM (7HD10 / 7HD80) + 2x IM 153-2
+ BM 2 x 40 / BM 1 x 80 + I- / O-modules
In the table, IM 153-2 stands for:
• IM 153-2 (6ES7153-2BA01-0XB0)
• IM 153-2 (6ES7153-2BA02-0XB0)
• IM 153-2 (6ES7153-2BA81-0XB0)
• IM 153-2 (6ES7153-2BA82-0XB0)
