Assignment planning
3.1 Structure variants for PROFIBUS DP
ET 200M
34 Operating Instructions, 12/2008, EWA-4NEB780600602-08
Structure variants in the outdoor area
Using the existing hardware you can realize the combinations listed in the following table in
the outdoor area.
Table 3- 2 ET 200M structure variants in the outdoor area
non-redundant configuration redundant configuration
• IM 153-2 + bus connector
+ I- / O-modules*
• BM IM/IM (7HD80) + IM 153-2
+ BM 2 x 40 / BM 1 x 80 (painted) *
+ I- / O-modules*
• BM IM/IM (7HD80) + 2x IM 153-2
+ BM 2 x 40 / BM 1 x 80 (painted) *
+ I- / O-modules*
* SIPLUS modules for use in expanded environmental conditions
In the table, IM 153-2 stands for IM 153-2 (6ES7153-2BA81-0XB0 or 6ES7153-2BA82-0XB0)
SIPLUS modules
For the outdoor area under the product names SIPLUS special S7-300 modules are
available. You can use these under expanded environmental conditions. Expanded
environmental conditions mean:
● can be used from –25 °C to +60 °C
● occasional, brief condensation is permitted
● increased mechanical load permitted
In the functional scope and in the technical data, the SIPLUS modules correspond to the
"standard" modules.
The SIPLUS S7-300 modules have their own order numbers. These are based on those of
the "standard" S7-300 modules, starting however with "6AG1…" instead of "6ES7…".
For more information on these modules, refer to the reference manual "S7-300 automation
system, module specifications
(http://support.automation.siemens.com/WW/view/en/8859629
)".
You´ll find more information on SIPLUS and contact partners for this area in the Internet
(http://www.automation.siemens.com/siplus/index_76.htm
).
Reference
● You´ll find detailed information regarding the functions and properties of the IM 153-2 in
chapter "Functions (Page 129)" and in the appendix "Functions (Page 129)".
● You´ll find detailed information on mechanical and climatic environmental conditions for
operating the ET 200M in chapter "General technical specifications of the reference
manual "S7-300 automation system, module specifications
(http://support.automation.siemens.com/WW/view/en/8859629
)".
● The IM 153-2Bxx1 is not just an interface module for the ET 200M, but also for the bus
connections DP/PA-link and Y-link. For the configuration variant options please refer to
the "DP/PA Link and Y Link bus links
(http://support.automation.siemens.com/WW/view/en/1142696
)" operating instructions.
See also
Compatibilities between the IM 153-x (Page 241)
