Technical Specifications
10.3 Technical specifications of the IM 153-x
ET 200M
Operating Instructions, 12/2008, EWA-4NEB780600602-08
231
10.3 Technical specifications of the IM 153-x
General technical specifications
In the "S7-300 automation system, module specifications
(http://support.automation.siemens.com/WW/view/en/8859629
)" reference manual you will
find for the interface module IM 153-x
● all the general technical data that applies for both the S7-300 and the ET 200M and
● the deviating technical data and tests for the interface module IM 153-x for expanded
environmental conditions ("outdoor") with the order numbers 6ES7153-1AA8x-0XB0 and
6ES7153-2BA81-0XB0.
Technical specifications of the IM 153 interface modules
The technical specifications for all functions of the various IM 153-x versions are included in
the following table. Check, together with the table "Properties and functions of the variants"
of IM 153-x in chapter "IM 153-x: Variants and properties (Page 17)" to see which version of
your IM 153-x supports these functions.
Technical Specifications IM 153-1 IM 153-2 IM 153-2 FO
Manufacturer ID 801D
H
801E
H
8071
H
GSD file SIEM801D.GSD SIEM801E.GSD SIEM8071.GSD
• for DPV1
SI01801D.GSG SI01801E.GSG
(for IM 153-2AA0x)
SI02801E.GSG
(for IM 153-2BA00)
SI03801E.GSG
(for IM 153-2BAx2)
SI04801E.GSG
(for IM 153-2BAx2)
SI018071.GSG
(for IM 153-2AB0x)
SI028071.GSG
(for IM 153-2BB00)
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight, c. 360 g
PROFIBUS DP interface
Baud rates Up to 12 MBaud 9,6; 19,2; 45,45;
93.75; 187.5;
500 kBaud;
1.5; 12 MBaud
Baud rate detection yes
Interface RS 485 FOC
FREEZE capability yes
SYNC capability yes
PROFIBUS addresses 1 to 125 permissible
System modification in RUN mode No yes
