Functions
8.2 Time stamping the input signals with IM 153-2
ET 200M
Operating Instructions, 12/2008, EWA-4NEB780600602-08
135
8.2.2.3 Time synchronization for time stamping
Requirements
The following requirements apply to the time synchronization for time stamping:
● There must be a clock master, e.g. SICLOCK TM available in the automation system. It
must work with synchronization intervals of 10 s.
● The time message frame must be forwarded:
– via Ethernet e.g. to a CP 443-1
– on PROFIBUS DP e.g. via an integrated DP master or CP 443-5 Extended
● For the IM 153-2 (as of 6ES7153-2BAx1-0XB0) a synchronization interval of 10 s must be
configured.
Time synchonrization for highly precise time stamping with 1 ms precision
You must realize the time synchronization for the highly precise time stamping with the
following hardware components and settings:
● Time master: SICLOCK TM (as of FW V3.3.0090) with GPS synchronization
Parameters to be set for SICLOCK TM:
Path / tab Parameter
(with number from the
SICLOCK parameter menu)
Value
Mode (218) Ramp
Step pos. (219)
Synchronization /
Redundancy
Synchronization
Step neg. (220)
Micro step
Input mode Input type (230) DCF
E1 active / passive TTY passive
Inputs
Input E1
DCF alarm (239) 5
LAN general LAN timeout (349) 0.5 s
Adr1 protocol (e.g. 350) Layer 2 - S5
Adr1 send (e.g. 351) 10 s
LAN 1-5
Adr1 def. (e.g. 352) broadcast
Adr1 is given as an example. Other LAN-connections / addresses have other
parameter numbers accordingly.
Ethernet
LAN extra SNTP server (550) off
