Siemens SIMATIC ET 200M

Interrupt, error and system messages
9.1 PROFIBUS DP
ET 200M
Operating Instructions, 12/2008, EWA-4NEB780600602-08
203
Table 9- 9 Error type of the channel-related diagnostic - manufacturer-specific
Error type Error text Meaning Remedy
10000
B
16
D
Parameter
configuration
error
Parameter configuration error, e.g.:
• Module cannot evaluate the parameter (unknown,
inadmissible combination, ...)
• Module not configured
• User calibration does not correspond to the configuration
• Calibration error
Correction of the
parameterization
10001
B
17
D
Encoder or load
voltage missing
The following voltages could me missing:
• external supply voltage
• Voltage to operate the module
Correction of the
process wiring
10010
B
18
D
Fuse faulty The user´s exchangeable fuse has failed Replace the fuse
10011
B
19
D
Communication
error
With F technology (PROFIsafe):
• Error with the consecutive number (sign of life)
• Error in the user data CRC
• User data timeout
Check the
communication paths
10100
B
20
D
Ground error Ground error, e.g.:
• The permissible common mode voltage for isolated
channels has been exceeded
• The M line is broken in the case of isolated channels
Correction of the
process wiring
10101
B
21
D
Reference
channel fault
Error on the reference channel Replace the reference
channel module
10110
B
22
D
Hardware
interrupt lost
Hardware interrupt has become lost Correction tuning of
program /
process / module
10111
B
23
D
Warning There could be a warning, if limit values like:
• Speed
• Load current
are exceeded
Correction tuning of
program /
process / module
11000
B
24
D
Switch off There could be a switch off:
• Power switch is triggered on account of short circuit,
asymmetry, contact to earth
• Thermistor triggered
• Quick stop
• fail-safe switch off
Remedy the cause of
switch off and
acknowledge
11001
B
25
D
fail-safe switch
off
Trigger / cause for fail-safe switch of is given Remedy the cause of
switch off
11010
B
26
D
External error External (process-side) error, e.g.:
• Sensor error
• Actuator error
• Sensor data is incorrect
Replace sensor /
actuator / correct
process wiring
11011
B
27
D
Unclear error Unclear errors are those that are not specified in any more
detail
different, depending on
cause of error
11100
B
28
D
reserved
