Interrupt, error and system messages
9.2 PROFINET IO
ET 200M
220 Operating Instructions, 12/2008, EWA-4NEB780600602-08
LEDs Meaning Remedy
SF BF MT ON
off off * on Data exchange is taking place between
the
IO controller and the ET 200M.
The preset configuration and actual
configuration of the ET 200M match.
—
on on * off FW update busy —
off Flash
es at
0.5
Hz
* off FW update successfully completed —
on Flash
es at
0.5
Hz
* off external error during FW update
(incorrect FW, for example)
• Use the correct FW for the update.
on Flash
es at
2 Hz
* off internal error during FW update
(possible read/write error)
• Repeat the FW update.
* * on on
• Loss of synchronization
• Network error
Also see Maintenance interrupts
(Page 222)
LINK RX/TX
off off There is no connection to the IO controller
(no IO controller available on the network)
• No uniform transmission rate
• Autonegotiation not successful
on * Autonegotiation completed and
PROFINET transmission rate accepted
—
on on Transmission/reception is in progress —
* not relevant
9.2.2 Diagnostic messages of the electronic modules
Actions after a diagnosis message
Every diagnostic message leads to the following actions:
● The SF LED on the interface module is lit.
● There can be more than one diagnostic message at the same time.
● Diagnostics data are reported as diagnosis interrupts and can be read from data records.
● Following a diagnostic message, the message is saved in the diagnostic buffer of the I/O
controller.
● Next, OB 82 will be called. If OB 82 is not available, the I/O controller goes to STOP
mode.
● Acknowledgment of the diagnostic interrupt to enable new interrupts.
