Installation
4.2 Installation
ET 200M
Operating Instructions, 12/2008, EWA-4NEB780600602-08
65
Step Activity Figure
3. Hook the modules onto the rail (1),
slide them along as far as the module on the left
(2), and swing them down into place (3).
(7
4. Bolt the modules tight, applying a torque of
between 0.8 and 1.1 Nm.
(7
