Page #158 background image
Technical specifications
Operational limit (across entire temperature range, relative to the measurement range end value in the selected input range)
Voltage input
± 5 V
± 10 V
1 V to 5 V
0 V to 10 V
± 50 mV
± 500 mV
± 1 V
± 0.6%
± 0.5%
Current input
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
± 0.5%
Resistor/PTC
0 kΩ to 6 kΩ
0 Ω to 600 Ω
PTC
± 0.5%
± 0.5%
± 0.5%
Resistance thermometer/silicon temperature sensors
Pt 100
Ni 100
Standard
± 1.2 K
Pt 100
Ni 100
Klima
± 1 K
Ni 1000,
LG-Ni 1000
Standard
± 1 K
Ni 1000
LG-Ni 1000
Klima
± 1 K
KTY83/110
KTY84/130
± 3.5 K
± 4.5 K
Basic error limit (operational limit at 25 °C, relative to the measurement range end value in the selected input range)
Voltage input
± 5 V
± 10 V
1 V to 5 V
0 V to 10 V
± 50 mV
± 500 mV
± 1 V
± 0.4%
± 0.3%
Current input
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
± 0.3%
Resistor/PTC
0 kΩ to 6 kΩ
0 Ω to 600 Ω
PTC
± 0.3%
± 0.3%
± 0.3%
ET 200PA SMART I/O modules
10.4 Analog input modules
ET 200PA SMART
158 Operating Instructions, 06/2019, A5E34192013-AB
