Siemens simatic et200sp User Manual

Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
135
User data variants
D
D.1
User data variants with 32 bytes input data / 12 bytes output data
User data
30 bytes are available for transferring the measured values in a cycle at the module version
32 I / 12 Q. Therefore this module version supports dynamic switching between 22
preconfigured user data variants that contain a specific selection of measured values.
For more detailed information, refer to "Selecting the module versions (Page 26)".
Table D- 1 Overview of the user data variants
User data
User data variant
Total power L1L2L3 254 (FE
H
) - default setting
Active power L1L2L3
253 (FD
H
)
Reactive power L1L2L3
252 (FC
H
)
Apparent power L1L2L3
251 (FB
H
)
Basic measured values L1L2L3
250 (FA
H
)
Total energy L1L2L3
249 (F9
H
)
Energy L1
248 (F8
H
)
Energy L2
247 (F7
H
)
Energy L3
246 (F6
H
)
Basic variables three-phase measurement
L1L2L3
245 (F5
H
)
Quality values three-phase measurement
240 (F0
H
)
Energy measurement (periodic) overflow counter
239 (EF
H
)
EE@Industry measurement data profile E3
227 (E3
H
)
EE@Industry measurement data profile E2
226 (E2
H
)
EE@Industry measurement data profile E1
225 (E1
H
)
EE@Industry measurement data profile E0
224 (E0
H
)
Basic variables phase-specific measurement L1
159 (9F
H
)
Basic variables phase-specific measurement L1a
158 (9E
H
)
Basic variables phase-specific measurement L2
157 (9D
H
)
Basic variables phase-specific measurement L2a
156 (9C
H
)
Basic variables phase-specific measurement L3
155 (9B
H
)
Basic variables phase-specific measurement L3a 154 (9A
H
)
User-defined user data structure
1 (01
H
)
