Product overview
2.2 Properties of the AI Energy Meter 480VAC ST
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
13
2.2
Properties of the AI Energy Meter 480VAC ST
Article number
6ES7134-6PA20-0BD0
View of the module
①
Module type and name
⑥
LED for supply voltage
②
LED for diagnostics
⑦
Function class
③
2D matrix code
⑧
Color identification label module type
④
Wiring diagram
⑨
Function and firmware version
⑤
LEDs for channel status
⑩
Article number
Image 2-2 View of the module AI Energy Meter 480VAC ST
