Configuration / address space
4.2 Selecting the module versions
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
28 Manual, 12/2015, A5E36061895-AA
Module versions at configuration with GSD file
Module versions with fixed user data assignment
2 I / 2 Q No cyclic user data.
Access to measured
values through "Read
2-byte inputs
2-byte outputs
Information about the structure of the 2 I / 2 Q
module version is available in the appendix Mod-
ule version "2 I / 2 Q" (Page 122).
E0 User data in accordance
with EE@Industry meas-
urement data profiles
12 byte inputs /
Information about the structure of the
EE@Industry measured data profiles is available
in the appendix Module version "EE@Industry
measurement data profile E0 / E1 / E2 / E3"
(Page 133).
E1 4 byte inputs /
E2 12 byte inputs /
E3 104 byte inputs /
Module versions with selectable user data variants
32 I / 12 Q User data selectable
through user data variants
or through user-specific
user data*
32 byte inputs /
You can change over the user data variant during
operation.
If you use user-specific user data, you write your
measured value profile into the AI Energy Meter
480VAC ST with the data record 130. To do this
use the WRREC instruction. Information about the
structure of data record 130 is available in appen-
dix Structure of the parameter data record 130 for
user-data mapping (Page 110).
64 I / 12 Q 64 byte inputs /
128 I / 12 Q 128 byte inputs /
256 I / 12 Q 256 byte inputs /
12 byte outputs
*Ensure that the user data do not exceed the size of the address space of the module ver
sion. If necessary, use a module
version with a larger address space
