Configuration / address space
4.2 Selecting the module versions
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
27
Module versions at configuration with STEP 7
Module versions with fixed user data assignment
2 I / 2 Q No cyclic user data.
Access to measured values
through "Read data record".
2-byte inputs
2-byte outputs
Information about the structure of the 2 I / 2 Q
module version is available in the appendix Module
version "2 I / 2 Q" (Page 122).
EE@Industry E0 User data in accordance with
EE@Industry measurement
data profiles
12 byte inputs /
Information about the structure of the EE@Industry
measured data profiles is available in the appendix
Module version "EE@Industry measurement data
profile E0 / E1 / E2 / E3" (Page 133).
EE@Industry E1 4 byte inputs /
EE@Industry E2 12 byte inputs /
EE@Industry E3 104 byte inputs /
Module versions with selectable user data variants
32 I / 12 Q User data selectable through
defined user data variants
32 byte inputs /
12 byte outputs
You can change over the user data variant during
operation.
Information about the structure of the 32 I / 12 Q
module version is available in the appendix Module
version "32 I / 12 Q" (Page 125).
Information about the user data variants at 32 I / 12
Q is available in the appendix User data variants
with 32 bytes input data / 12 bytes output data
User-specific User data selectable through
user data mapping or through
defined user data variant
Variable* /
12 byte outputs
You have to activate the check box "User da-
ta-mapping" in STEP 7 to use the module version
user-specifically.
You can change over the user data variant during
operation.
Information about the structure of the user-specific
module version is available in the appendix "User-
specific" module version (Page 131).
* 16 ... 256 bytes in steps of 16 bytes, depending on the mapped measured values
