Configuration / address space
4.3 Applicable modules
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
31
4.3
Applicable modules
Configuring with STEP 7
The following table shows with which controllers the different module versions can be
configured with STEP 7.
Table 4- 1 Module versions configured with STEP 7
Controller
Module version
2 I / 2Q
32 I / 12 Q
User-specific
EE@Industry measurement data profile
E0
E1
E2
E3
IM 155-6 PN ST V1.0 or higher V1.0 or higher*
V3.1 or higher
V1.0 or higher V3.1 or higher
IM 155-6 PN HF V2.0 or higher V2.0 or higher*
V3.1 or higher
V2.0 or higher V3.1 or higher
IM 155-6 PN BA
V3.2 or higher
---
V3.2 or higher
---
IM 155-6 PN HS
V4.0 or higher
IM 155-6 DP HF
V1.0 or higher
---
V1.0 or higher
---
CPU 1510SP-1 PN V1.6 or higher V1.6 or higher*
V2.0 or higher
V1.6 or higher V2.0 or higher
CPU 1510SP F-1 PN V1.7 or higher V1.7 or higher*
V2.0 or higher
V1.7 or higher V2.0 or higher
CPU 1512SP-1 PN V1.6 or higher V1.6 or higher*
V2.0 or higher
V1.6 or higher V2.0 or higher
CPU 1512SP F-1 PN V1.7 or higher V1.7 or higher*
V2.0 or higher
V1.7 or higher V2.0 or higher
CPU 1515SP PC V1.7 or higher V1.7 or higher*
V2.0 or higher
V1.7 or higher V2.0 or higher
* Only up to 32 bytes
