Measured value data records
E.5 Measured value data record for minimum values (DS 145)
Analog input module AI Energy Meter 480VAC ST (6ES7134-6PA20-0BD0)
Manual, 12/2015, A5E36061895-AA
165
Byte
Measured variable
Format
Unit
Default
Measured
value ID
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
90...93 Max. total apparent
power
REAL VA 0 65 ✓ ✓ ✓ ✓ ✓
94...97 Max. total active
power
REAL W -3.0 x 10
9
66 ✓ ✓ ✓ ✓ ✓
98...101 Max. total reactive
power
REAL var -3.0 x 10
9
67 ✓ ✓ ✓ ✓ ✓
102 Max. total power
factor
REAL - 0 68 ✓ ✓ ✓ ✓ ✓
1
The values reference the amount of the current measured value
E.5
Measured value data record for minimum values (DS 145)
Measured variables of the module
The smallest values ever measured or calculated from the time AI Energy Meter 480VAC ST
was started are stored in this data record.
Byte
Measured variable
Format
Unit
Default
Measured
value ID
Connection type
1P2W
3x1P2W
2P3W
3P4W
3P4W1
0
Version
BYTE
-
0
-
✓
✓
✓
✓
✓
1
Reserved
BYTE
-
0
-
✓
✓
✓
✓
✓
2...5
Min. voltage UL1-N
REAL
V
1000000
70
✓
✓
✓
✓
✓
6...9
Min. voltage UL2-N
REAL
V
1000000
71
✓
✓
✓
✓
10...13
Min. voltage UL3-N
REAL
V
1000000
72
✓
✓
✓
14...17
Min. voltage UL1-L2
REAL
V
1800000
73
✓
✓
18...21
Min. voltage UL2-L3
REAL
V
1800000
74
✓
✓
22...25
Min. voltage UL3-L1
REAL
V
1800000
75
✓
✓
26...29
Min. current L1
1
REAL
A
100000
76
✓
✓
✓
✓
✓
30...33
Min. current L2
1
REAL
A
100000
77
✓
✓
✓
✓
34...37
Min. current L3
1
REAL
A
100000
78
✓
✓
✓
38...41 Min. apparent power
L1
REAL VA +3.0 x 10
9
79 ✓ ✓ ✓ ✓ ✓
42...45 Min. apparent power
L2
REAL VA +3.0 x 10
9
80 ✓ ✓ ✓ ✓
46...49 Min. apparent power
L3
REAL VA +3.0 x 10
9
81 ✓ ✓ ✓
50...53
Min. active power L1
REAL
W
+3.0 x 10
9
82
✓
✓
✓
✓
✓
54...57
Min. active power L2
REAL
W
+3.0 x 10
9
83
✓
✓
✓
✓
58...61
Min. active power L3
REAL
W
+3.0 x 10
9
84
✓
✓
✓
62...65 Min. reactive power
L1
REAL var +3.0 x 10
9
85 ✓ ✓ ✓ ✓ ✓
